MDR 20 pin male to male HPCN scsi cable with ABS Shell and latch

MDR 20 pin male to male HPCN scsi cable with ABS Shell and latch

Applications:

  • MDR 20 pin male to male HPCN SCSI cable with ABS Shell and latch.
  • Connector A:1 MDR 20-pin male.
  • Connector B: 1 MDR 20-pin male.
  • Cable length: 1/3/5m or Customized.
  • Application: Workstations, RAID, CD ROM, File servers, Motion control card, and Networking equipment.


Product Detail

Product Tags

Technical Specifications
Warranty Information
Part number                                                                STC-Z003

Warranty                                                                      3 Years

Hardware
Cable Jacket Type                                                       PVC - Polyvinyl Chloride
Performance
Type and Rate                                                             SCSI/MDR/HPCN
Connector(s)
Connector A                                                                 1 - MDR SCSI-20Pin Male

Connector B                                                                 1 - MDR SCSI-20Pin Male

Physical Characteristics
Cable Length                                                               1/3/5m or Customized

Color                                                                            Black or Gray

Connector Style                                                           Straight

Product Weight                                                            0.12 kg

Wire Gauge                                                                  UL20276 28AWG*10P+AEB OD=7.0MM

Packaging Information
Package Quantity                                                        1Shipping (Package)

Weight                                                                          0.16 kg

What's in the Box

MDR 20 pin male to male HPCN SCSI cable with ABS Shell and latch  Cable

Overview



Product Description



SCSI 20 Pin MDR Male HPCN Solder Plug Connector cable assembly.



Bulk high-quality 20pin male SCSI cable assembly pin manufacturers, SCSI cables are the standard for small computer system interfaces and are mainly used for high-speed bus connections between small computers and intelligent peripherals such as printers, hard disks, and CD ROM drives, It Transmits high-speed and mission-critical data integrity associated with SCSI applications.

1> Wired straight through for extending serial devices/peripherals.

2> 360 degree fully shielded for protection against EMI/RFI.

3> Gold-plated contacts provide reliable connections with repeated mating cycles.

4> We could according to the customers' design specs make wire harnesses.



https://www.stc-cable.com/mdr-20-pin-male-to-male-hpcn-scsi-cable-with-abs-shell-and-latch.html



Advantage

1> Premium Cable for reliable and durable system performance.

2> Excellent shielding interference effect.

3> The connector minimizes induced signal noise.

4> Flexible yet has a single-end impedance of 90 ohms.

5> Used in testing devices for FCC and CE Acceptance
