Applications:

  • Connect a DVI enabled monitor or display to your DisplayPort source. Supports DisplayPort 1, 2, and 4 lanes at 1.62 Gbps and 2.7 Gbps
  • Clear picture quality with video resolution up to 1920×1080 and 4Kx2K @30Hz and full HDCP 1.3 content protection support
  • Keep your legacy DVI monitor and eliminate need to purchase expensive DP monitor. Great for using any DVI monitor as a secondary display and boosting productivity.
  • Compact design and easy to use; includes ESD protection: human body at 8KV and charge device at 2KV
  • Active DisplayPort to DVI converter supports multiple monitors with AMD Eyefinity Multi-Display Technology compatibility; Audio is not supported over DVI and must be transmitted separately with this DP to DVI adapter


Product Detail

Product Tags

Our company promises all users of the first-class products and the most satisfying post-sale service. We warmly welcome our regular and new customers to join us for Factory Customized Mobile Charger Cable Mode2-Type1 B with Screen 16A 250V Portable EV Charge LCD Display Control Box J1772 32 AMP Type 2 EV Cable Electric Vehicle Charger, We sincerely hope to establish some satisfactory associations along with you from the close to long run. We're going to preserve you informed of our progress and stay up for building steady organization relations along with you.
Our company promises all users of the first-class products and the most satisfying post-sale service. We warmly welcome our regular and new customers to join us for China Charger Electric Wall Mounted and EV Charger, We critically promise that we deliver all the customers with the best quality solutions, the most competitive prices and the most prompt delivery. We hope to win a resplendent future for customers and ourselves.

Technical Specifications
Warranty Information
Part number                                                                  STC-MM022

Warranty                                                                       2-Years

Hardware
Active or Passive Adapter                                             Active

Adapter Style                                                                Adapter

Output Signal                                                                DVI-D (DVI Digital)

Converter Type                                                             Format Converter

Performance
Maximum Digital Resolutions                                       4k*2k/ 60Hz or 30Hz
Supported Resolutions:1920×1080 (1080p)
1680×1050 (WSXGA+)
1600×1200
1600×900
1440×900
1400×1050 (SXGA+)
1366×768
1360×768
1280×1024
1280×960
1280×800
1280×768 (WXGA)
1280x720p (720p)
1280×600
1152×864
1024×768
800×600 (SVGA)
640×480 (480p)Wide Screen Supported                         Yes
Connectors
Connector A                                                                    1 -DisplayPort (20 pin) Latching Male

Connector B                                                                    1 -DVI-I (29 pin) Female

Environmental
Humidity                                                                        < 85% non-condensing

Operating Temperature                                                    0°C to 50°C (32°F to 122°F)

Storage Temperature                                                     -10°C to 75°C (14°F to 167°F)

Special Notes / Requirements
DP++ port (DisplayPort ++) required on video card or video source(DVI and HDMI pass-through must be supported)
Physical Characteristics
Products Length                                                               8 in (203.2 mm)

Color                                                                                Black

Enclosure Type                                                                Plastic

Packaging Information
Package Quantity                                                            1Shipping (Package)
What’s in the Box

DisplayPort to DVI Active Adapter

Overview



DisplayPort to DVI

The STC Active DisplayPort to DVI Adapter is an indispensable companion for your laptop or desktop equipped with DisplayPort. Connect your computer to a monitor for high-definition video streaming with this portable adapter and a DVI cable (sold separately). Extend your desktop to a second monitor for an expanded workstation.

This active adapter supports AMD Eyefinity Multi-Display Technology.

Product Specifications

Chipset: Parade PS171
Compliant with DisplayPort Interoperability specification v1.1a receiver
Compliant with DVI specification up to 1.65 Gbps Full HDCP 1.3 content protection support

Display modes:
- PC VGA, SVGA, XGA, SXGA and UXGA display modes
- HDTV: 480i, 576i, 480p, 576p, 1080i, 1080p and 4K2K @ 30Hz

ESD protection: human body at 8KV and charge device at 2KV
Adapter type: Active

Product:
- Overall Length: 10.59"
- Weight: 0.17 lbs
- Color: Black
- Material: ABS Mold

Connectors:
- 20-Pin DisplayPort (male) to 24+5 pin DVI-D (female)
- DisplayPort connector housing (L x W x H): 1.93" x 0.78" x 0.51"
- DVI connector housing (L x W x H): 2.76" x 0.67" x 1.65"

Environmental conditions:
- Operating temperature: 32 to 122 degrees F
- Storage temperature: 14 to 167 degrees F

https://www.stc-cable.com/displayport-to-dvi-active-adapter.html

FAQ

Question: Will this support 144hz on a 1920x1080 monitor?

Answer: Hi Jake, This product supports up to 1920x1200 (or 1080P) @60Hz or 30Hz Please email leo@stccable.com if you have any further questions. Thanks,

Question: This adaptor looks like it is a dual-link DVI adaptor. Is it a dual-link DVI adaptor?

Answer: Yes. It is DVI-I Dual Link

Question: Will this work with a DVI-i single link ( analog and digital) cable?

Answer: Yes, it's a DL DVI-i connector

Question: I can't get my fourth monitor to display with my R9 290. Maybe my generic DisplayPort is a passive one? Will this active adapter can solve my problem?

Answer: Yes, this active adapter will help. Please email leo@stccable.com if you have any further questions. Thanks,

Customer Feedback

"you should only be buying ACTIVE adapters. some display configurations won't work with a passive adapter and they cost almost the same in a quality brand. In a sub-par brand when you open up a passive adapter sometimes all the wires are not even connected!
I like this model, well constructed, supported ultra high res modes and 3-4 screen setups on my ATI and NVIDIA cards. I keep one of these in my go bag as a swiss army tool at all times to be able to hook up projectors and extra displays."

"This product works for my application. It has DisplayPort (male) and DVI female ports, and they were covered with plastic caps to keep the ports dust and debris free. All pins appeared to be present in the DVI port to support the use of a Dual Link DVI-D cable, and the adapter is Active. Though, the adapter does not accept an external power source. So, if your conversion requires external power, this adapter may not work for you. I am using it in a Dell docking station that only had DisplayPort and HDMI outs, whereas my monitor had only VGA and DVI inputs. It seems to work well enough so far (1900 x 1200 resolution at 60Hz), but my application is simple, and doesn't require close scrutiny on the quality of the video output.
So far, I've only used it for a few days, but it displayed the video where my passive adapter failed to do so."

"Works great with Eyefinity. The workstation-class AMD FirePro cards had a recent update to Catalyst that reports the type of connection on each port with additional technical details. This adapter causes the connection to be reported as a native DisplayPort-to-DisplayPort, eliminating any issues caused by passive adapters and allowing seamless operation of 3+ simultaneous displays. There is a slight flicker on the third LCD but I have no indication at this point it's caused by the adapter; will update after I swap some cables and other variables if it's an adapter issue. Barring that possibility, 5 stars all the way."

"Works with a GTX 980 to drive a third monitor (1 DVI, 1 HDMI, and one HDMI to DisplayPort- i.e. this adapter). I had some hiccoughs getting Nvidia control panel to play friendly with the 3 different inputs, but I don't fault the adapter for this. Picture quality is great: I don't notice any difference between it and my other inputs. My only complaint would be that the monitor attached to the adapter is slower to turn on at startup, or to update when resolutions are changed, etc. This doesn't have any bearing on normal use, however (the monitor hooked up to the adapter doesn't lag behind the others frame-wise when watching videos, working on the desktop, playing games, or anything like that.)
In summary, I've all but forgotten which monitor is hooked up to the adapter: and that's how it should be. Had it for a month, no problems. Good Product; met all my expectations."

"Works perfectly. I am able to simultaneously run 3 monitors on my desktop computer, and it works perfectly. The video card is AMD Radeon R9 270X HAWK. You need an ACTIVE DisplayPort to run 3 monitors, this is an ACTIVE DisplayPort."
