Warranty                                                                       3- Years

Connector B                                                                  1 - DB-HD50 (50 pins, D-Sub) Male

Color                                                                             Black/Gray

Connector Style                                                            Straight

Product Weight                                                             0.14kg

Wire Gauge                                                                  UL2464 28AWG*50C, OD=8.5mm

Weight                                                                          0.15kg

High-quality D-sub 50Pin male to male Cable DB 50pin male cable 1m for electronic.

D-sub Connector DB50 male-to-male cable

1> DB50 male to female connectors; lengths range from 1.0 ft to 50 ft; color is light gray or Black

2> Gold-plated contacts provide reliable connections with repeated mating cycles.

3> Double shielded for protection against EMI/RFI.

4> Hex nuts on female connectors are removable to expose 4-40 thumb screws.

5> Wired straight through for extending serial devices/peripherals.

6> This cable is a straight-through patch cable that features 50-pin D Sub DB50 connectors.

7> Available in multiple cable lengths to meet your specific requirements.

8> Cables can be easily cut in half and custom-terminated for prototyping.

9> RoHS compliant

50-Pin D-Sub cable assemblies by STC provide the perfect I/O solution for your DB50-equipped devices. All of our 50-pin d sub cables come fully populated with gold-plated contacts and molded DB50 connectors and offer varying degrees of shielding depending upon your specific requirements.

50-pin (DB50) Copper Shielded High-Density Male/Female D-Sub Cables by STC provide exceptional performance in commercial, industrial, or enterprise applications where longevity and repeated disconnects are required. Our fully assembled Deluxe HD D-Sub Cable integrates copper tape + aluminum mylar shielded 26 AWG data-grade wire with pre-terminated DB50 male and female d-sub connectors. Perfect for RS232 serial data, prototype, control, and low-voltage applications using the 50-pin DB50 interface.

General Description

These are extender cables for devices that use a DB-50 connector. All 50 pins are extended, and the wiring is straight-through (pin 1 to pin 1, 2 to 2, ...) including a foil shield around the cable and connecting the shells. The wire gauge is 28AWG. These cables are beige/grey. These cables have 3-row connectors.

Technically, the correct term for a DB50 connector is DD50, but that term is not commonly used.

Product Details

1> Available in Male-Female, Male-Male

2> All pins wired 1:1 (e.g. pin 1 to pin 1, pin 2 to pin 2, etc.)

3> 28 AWG conductors

4> Foil shielded
